Grizzly G1033 User Manual

-30- G1033 20" Planer
01 P1033001 HEADCASTING
02 PSS13M SETSCREW M10-1.5 X 12
03 P1033003 CUTTERHEAD
04 P1021103 SPRING
05 P1033005 BLADES FOR PLANER
06 P1033006 GIB
07 PB17M HEX BOLT M8-1.25 X 10
08 P1021166 KNIFE GAUGE W/BAR
12 P6206 BEARING 6206
13 PK09M KEY 8 X 8 X 36
14 P1021007 CUTTERHEAD PULLEY
15 P1033015 WASHER
5
/16" X 1
3
/16"
16 PSS12M SETSCREW M6-1.0 X 25
17 P1021008 MOTOR PULLEY
18 P1033018 INFEED ROLLER
19 P1021153 BUSHING BLOCK
20 P1021152 SPRING
21 P1033021 SPECIAL SETSCREW
22 P1021092 PLATE
23 PB09M HEX BOLT M8-1.25 X 20
24 PSS11M SETSCREW M6-1.0 X 16
25 PN01M HEX NUT M6-1.0
26 PK21M KEY 5 X 5 X 23
29 PB18M HEX BOLT M6-1.0 X 15
30 P1033030 OUTFEED ROLLER
31 P1021149 SPROCKET
32 P1033032 LOCKING ROD
33 PR03M SNAP RING 12MM
34 P1033034 CHIP BREAKER
35 PN09M HEX NUT M12-1.75
36 P1021028 CHIP BREAKER SPRING
37 PW03M FLAT WASHER 6MM
38 PB03M HEX BOLT M6-1 X 12
39 P1033039 SHAFT
40 P1033040 BRACKET
41 P1033041 PRESSURE PLATE
42 PLW04M LOCK WASHER 8MM
43 P1033043 SHAFT
44 PSS11M SETSCREW M6-1.0 X 16
45 PSS11M SETSCREW M6-1.0 X 16
46 P1033046 SPRING PLATE
47 P1033047 CHIP DEFLECTOR PLATE
48 P1021161 ANTI-KICKBACK FINGER
49 P1021160 SPACER
50 P1033050 SHAFT
51 PEC06M E-CLIP 20MM
52 P1033052 DEPTH LIMITER
53 PFH02M FLT HD SCR M6-1.0X12
54 P1033054 UPPER COVER
55 P1033055 GASKET
56 P1033056 COLLECTOR
57 P1033057 ROLLER STAND
58 P1033058 ROLLER
59 PSB01M CAP SCREW M6-1.0 X 16
60 P1033060 WORM GEAR BOX
61 PSB37M CAP SCREW M6-1.0 X 50
62 P1033062 WORM
63 P6201 BEARING 6201
64 PR29M SNAP RING 32MM
65 PK05M KEY 4 X 4 X 10
66 P1033066 HANDWHEEL
67 P1033067 WASHER
1
/2" X 1
1
/8"
68 P1021032 HANDLE
69 P1033069 SCALE
70 PS08M PHLP HD SCR M5-0.8X12
73 P1033073 COVER
75 P1033075 SAFETY HATCH
76 PB04M HEX BOLT M6-1.0X10
77 P1033077 SAFETY HATCH
78 PSB12M CAP SCREW M8-1.25 X 16
79 P1033079 PULLEY GUARD
80 P1033080 STUD
81 PW07 FLAT WASHER
5
/16"
82 PN02 HEX NUT
5
/
16" X 18
83 PVM59 V-BELT M59 3L590
84 P1033084 PULLEY COVER
85 P1033085 KNOB
86 P1033086 SWITCH BRACKET
87 G4573 MAGNETIC SWITCH
88 PN06M HEX NUT M5-0.8
89 P1033089 NAME PLATE
90 P1183095 RIVET
91 P1033091 CHAIN 33 LINKS
92 P1071075 STRAIN RELIEF
93 P1033093 POWER CORD
94 P1033094 STAR WASHER #10
95 PSB04M CAP SCREW M6-1.0X10
96 PSS14M SETSCREW M8-1.25X12
97 P1033097 RETAINER
98 P1033098 COLLAR
107 PLW03M LOCK WASHER 6MM
108 PS09M PHLP HD SCR M5-0.8X10
109 PSW01-1 PLASTIC SCREW
REF PART # DESCRIPTION REF PART # DESCRIPTION
