Model G4002/G4003 (Mfd. Since 3/14)

REF PART # DESCRIPTION REF PART # DESCRIPTION

501 P4002501 SADDLE 522 P4002522 SLIDE PLATE

502 P4002502 PHLP HD SCR M3-.5 X 14 523 P4002523 SLIDE PLATE

503 P4002503 WIPER 524V2 P4002524V2 SLIDE PLATE 3 HOLES V2.01.09

504 P4002504 PHLP HD SCR 8-32 X 3/8 525 P4002525 HEX BOLT M8-1.25 X 24

505 P4002505 COVER 526 P4002526 WIPER

506 P4002506 CAP SCREW M5-.8 X 14 528 P4002528 HANDLE

507 P4002507 WIPER 529A P4002529A BRACKET

508 P4002508 ROLL PIN 5 X 45 530A P4002530A SET SCREW

509 P4002509 CAP SCREW M8-1.25 X 35 531A P4002531A SPANNER NUT

510 P4002510 SCREW 533 P4002533 SIGN BOARD

511 P4002511 SCREW 534 P4002534 RIVET 2 X 3MM STEEL

512 P4002512 CROSS SLIDE 535 P4002535 THRUST BEARING 51102

513 P4002513 GIB 536 P4002536 BRACKET

514 P4002514 BUSHING 537 P4002537 CAP SCREW M6-1 X 25

515 P4002515 CROSS SLIDE NUT M8-1.25, BRASS 539 P4002539 CROSS SLIDE LEADSCREW

518 P4002518 SLIDE PLATE 540 P4002540 GEAR 13T

519 P4002519 CAP SCREW M8-1.25 X 25 541 P4002541 CAP SCREW M6-1 X 8

520 P4002520 WIPER 542 P4002542 DIAL

521 P4002521 SCREW

Saddle Parts List
