-56-
Model G4002/G4003 (Mfd. Since 3/14)
820
Motor Assembly
REF PART # DESCRIPTION REF PART # DESCRIPTION
801 P4002801 COVER 815 P4002815 KEY
802 P4002802 SCREW 816 P4002816 PULLEY
803 P4002803 NUT 817 P4002817 MOTOR MOUNT BRACKET
812 P4002812 MOTOR 2 HP 1.1KW V2.12.97 818 P4002818 FLAT WASHER 12MM
813 P4002813 FLAT WASHER 10MM 819 P4002819 HEX BOLT M10-1.5 X 30
814 P4002814 HEX BOLT M10-1.5 X 30 820 P4002820 V-BELT A29
