Model G4176 (Mfd. Since 5/14)
-3-
Machine Data Sheet
The information contained herein is deemed accurate as of 9/13/2012 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
PAGE 1 OF 2Model G4176
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G4176 1/4 HP POWER FEEDER
Product Dimensions:
Weight................................................................................................................................................................ 73 lbs.
Width (side-to-side) x Depth (front-to-back) x Height........................................................................... 34 x 13 x 24 in.
Footprint (Length x Width)........................................................................................................................... N/A x N/A
Shipping Dimensions:
Type............................................................................................................................................................. Cardboard
Content........................................................................................................................................................... Machine
Weight................................................................................................................................................................ 79 lbs.
Length x Width x Height....................................................................................................................... 23 x 23 x 11 in.
Electrical:
Power Requirement........................................................................................................... 120V, Single-Phase, 60 Hz
Minimum Circuit Size.............................................................................................................................................. 15A
Switch..................................................................................................................................... Forward/Reverse Barrel
Switch Voltage..................................................................................................................................................... 120V
Cord Length............................................................................................................................................................ 9 ft.
Cord Gauge.................................................................................................................................................... 18 AWG
Plug Included.......................................................................................................................................................... Yes
Included Plug Type.................................................................................................................................... NEMA 5-15
Motors:
Main
Type.................................................................................................................. TEFC Capacitor Start Induction
Horsepower............................................................................................................................................. 1/4 HP
Voltage....................................................................................................................................................... 120V
Phase....................................................................................................................................................... Single
Amps........................................................................................................................................................... 2.5A
Speed................................................................................................................................................ 1660 RPM
Cycle......................................................................................................................................................... 60 Hz
Number of Speeds............................................................................................................................................ 1
Power Transfer ................................................................................................................................... Gear Box
Bearings................................................................................................................................. Lubricated for Life
Main Specifications:
Workpiece Capacities
Minimum WorkPiece Length........................................................................................................................ 5 in.
Operation Info
Number of Feed Speeds.................................................................................................................................. 4
Feed Speeds........................................................................................................................ 18, 25, 30, 41 FPM
Swing.................................................................................................................................................... 360 deg.
Vertical Movement................................................................................................................................. 6-1/2 in.
Horizontal Movement................................................................................................................................. 10 in.
Rotation.................................................................................................................................. Forward, Reverse
