Grizzly G4176 - Components & Terminology

Model G4176 (Mfd. Since 5/14)
-5-
Components & Terminology
Refer to Figure 1 and your power feeder to familiarize yourself with the controls, features, and terminology
used in this manual. Doing so will make setup, use, and any future maintenance easier.
Horizontal
Handcrank
Vertical
Travel
Lock
Lever
Rotary
Movement
Lock Lever
Vertical Travel
Handcrank
Horizontal
Travel Lock
Lever
1
⁄4 HP
Motor
Elbow Joint Lock Lever
Elbow Joint Lock Lever
Gearbox Oil Port
Behind Elbow Joint
To reduce your risk of
serious injury, read this
entire manual BEFORE
using machine.
Figure 1. Controls and features.
