G9742 Metal Cutting Bandsaw (Mfg. Since 11/06
-3-
The information contained herein is deemed accurate as of 1/31/2013 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
PAGE 1 OF 2Model G9742
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G9742 5" X 6" METAL-CUTTING BANDSAW W/
SWIVEL HEAD
Product Dimensions:
Weight.............................................................................................................................................................. 150 lbs.
Width (side-to-side) x Depth (front-to-back) x Height............................................................... 39 x 23-3/8 x 54-3/4 in.
Footprint (Length x Width)............................................................................................................... 26-1/2 x 20-1/2 in.
Shipping Dimensions:
Type................................................................................................................................................... Wood Slat Crate
Content........................................................................................................................................................... Machine
Weight.............................................................................................................................................................. 168 lbs.
Length x Width x Height....................................................................................................................... 41 x 18 x 22 in.
Must Ship Upright................................................................................................................................................... Yes
Electrical:
Power Requirement............................................................................................. 110V or 220V, Single-Phase, 60 Hz
Prewired Voltage.................................................................................................................................................. 110V
Full-Load Current Rating...................................................................................................... 7A at 110V, 3.5A at 220V
Minimum Circuit Size.......................................................................................................... 15A at 110V, 15A at 220V
Switch...................................................................................................... Sealed Button Switch w/Automatic Shut-Off
Cord Length............................................................................................................................................................ 6 ft.
Cord Gauge.................................................................................................................................................... 18 AWG
Plug Included.......................................................................................................................................................... Yes
Motors:
Main
Type................................................................................................................. TEFC Capacitor-Start Induction
Horsepower............................................................................................................................................. 1/2 HP
Phase............................................................................................................................................ Single-Phase
Amps...................................................................................................................................................... 7A/3.5A
Speed................................................................................................................................................ 1725 RPM
Power Transfer ............................................................................................................................... V-Belt Drive
Bearings..................................................................................................... Shielded & Permanently Lubricated
Main Specifications:
Operation Info
Blade Speeds......................................................................................................................... 80, 120, 200 FPM
Std. Blade Length................................................................................................................................ 64-1/2 in.
Blade Size Range..................................................................................................................................... 1/2 in.
Head Swivel............................................................................................................................................ 45 deg.
