MODEL G9742
5"x 6" METAL-CUTTING
BANDSAW w/ SWIVEL HEAD
OWNER'S MANUAL
(For models manufactured since 11/06)
COPYRIGHT © NOVEMBER, 2005 BY GRIZZLY INDUSTRIAL, INC. REVISED FEBRUARY, 2013 (TS)
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
#PC7670 PRINTED IN CHINA

Table of Contents

Questions and Answers

  • T
    tyler90Aug 18, 2025
    Why does the blade on my Grizzly G9742 Saw dull prematurely?
    • W
      William MartinAug 18, 2025
      If the blade on your Grizzly Saw is dulling prematurely, it could be due to several reasons. The cutting speed might be too fast. The blade TPI might be too coarse. The blade feed pressure might be too light. If the workpiece has hard spots, welds, or scale, increase the feed pressure and reduce the cutting speed. The blade might be twisted, in which case you should replace it. The blade might be slipping on the wheels.
  • K
    Kimberly SerranoAug 20, 2025
    What to do if the cuts are crooked with my Grizzly Saw?
    • M
      Michael MitchellAug 21, 2025
      Crooked cuts with your Grizzly Saw can stem from several issues. The feed pressure might be too high. The guide bearings could be out of adjustment or too far from the workpiece. Low blade tension can also cause this problem. A dull blade is a common culprit. The blade speed might be incorrect.
  • J
    Judy WrightAug 28, 2025
    Why do the blades on my Grizzly G9742 break often?
    • G
      gloriabarajasAug 28, 2025
      If blades break often on your Grizzly Saw, consider these potential causes: * The blade might not be tensioned correctly—ensure it's neither too tight nor too loose. * A loose workpiece in the vise can cause blade breakage—clamp it tighter or use a jig. * Incorrect feed or cut speed can be a factor—adjust as needed. * Using a blade with a TPI that's too great for the material can lead to breakage. * If the blade is rubbing on the wheel flange, adjustment is needed. Additionally, starting the bandsaw with the blade resting on the workpiece, misaligned guide bearings, or using a blade that is too thick or of low quality can all contribute to frequent blade breakage.
  • J
    Joy MarshallAug 29, 2025
    How to fix vibration or noisy operation in my Grizzly G9742 Saw?
    • K
      Katelyn JacobsAug 30, 2025
      If your Grizzly Saw is vibrating or operating noisily, several factors could be contributing. The motor fan might be rubbing on the fan cover, which would require replacing a dented fan cover or a loose/damaged fan. A faulty blade could also be the cause, so consider replacing or resharpening it. Issues within the gearbox, such as bad gears or bearings, can also lead to noise and vibration, necessitating a gearbox rebuild. Finally, using the wrong blade at too slow a speed can cause these issues, so try changing the blade and/or speed.
  • A
    Amanda ScottSep 1, 2025
    Why are teeth ripping from the blade on my Grizzly Saw?
    • S
      Sonia UnderwoodSep 1, 2025
      If teeth are ripping from the blade on your Grizzly Saw, it could be due to a few reasons. The feed pressure might be too heavy and the blade speed too slow, or the blade TPI might be too coarse for the workpiece; decrease the feed pressure. The workpiece could be vibrating in the vise; re-clamp the workpiece in the vise, and use a jig if required. The blade gullets might be loading up with chips; use a coarser-tooth blade.
  • A
    Amber WhiteSep 3, 2025
    Why does my Grizzly G9742 trip the breaker?
    • C
      Caleb JohnsonSep 3, 2025
      Your Grizzly Saw might be tripping the breaker due to several reasons. It could be a blown fuse or a tripped circuit breaker, in which case you should ensure it's the correct size for the machine load and replace any weak breakers. Other potential causes include a faulty start capacitor (test and replace if necessary), incorrect motor connection wiring (correct the connections), a faulty ON/OFF switch (replace it), or an issue with the power supply (ensure correct voltage and that the main power is ON). Also, check for broken or disconnected wires and repair/replace them. In some cases, the motor itself may be at fault, requiring testing, repair, or replacement.
  • T
    thomasrebekahSep 8, 2025
    How to fix a Grizzly Saw that won't start?
    • D
      Denise ColemanSep 8, 2025
      If your Grizzly Saw won't start, begin by checking the power supply to ensure it's properly switched ON and that hot lines have the correct voltage on all legs. Inspect the plug and receptacle for any faults or incorrect wiring; test for good contacts and correct the wiring if needed. A faulty ON/OFF switch could also be the culprit, so consider replacing it. Also, check for broken wires or disconnected/corroded connections, repairing or replacing them as necessary. In some cases, the motor itself may be at fault, requiring testing, repair, or replacement.
  • K
    Kathy NavarroSep 12, 2025
    Why is my Grizzly G9742 vibrating?
    • J
      jorgethomasSep 12, 2025
      If your Grizzly Saw is vibrating or operating noisily, possible causes include the motor fan rubbing on the fan cover (replace the dented cover or the loose/damaged fan), a faulty blade (replace or resharpen it), or a fault within the gearbox (rebuild the gearbox for bad gears or bearings). Also, ensure you are using the correct blade and speed combination; adjust as necessary.
  • D
    Diana PrinceSep 12, 2025
    What to do if my Grizzly G9742 motor won't start?
    • L
      Linda SmithSep 12, 2025
      If your Grizzly Saw motor won't start, several issues could be responsible. A faulty start capacitor could be the cause; test it and replace if necessary. Also, make sure the motor connection is wired correctly by correcting any incorrect motor wiring connections. If these steps don't resolve the issue, the motor itself may be at fault, requiring testing, repair, or replacement.
  • K
    Kristin MillerSep 15, 2025
    Why is my Grizzly G9742 Saw underpowered?
    • S
      Stephen DaviesSep 15, 2025
      Your Grizzly Saw may be underpowered for a few reasons. The issue may be low power supply voltage, so ensure the hot lines have the correct voltage on all legs. Another possibility is that the motor has overheated; clean it off, let it cool, and reduce the workload. Also, the motor itself may be at fault, requiring testing, repair, or replacement.

Summary

Introduction

Foreword

Welcome message and overview of the manual's purpose and the bandsaw.

Contact Information

Grizzly Industrial contact details for comments, support, and service inquiries.

Machine Data Sheet

Product and Shipping Specifications

Details on machine weight, dimensions, and shipping requirements.

Electrical and Motor Details

Information on power requirements, voltage, current, and motor specifications.

Cutting Capacities and Construction

Maximum material sizes and construction materials of key machine parts.

Table and Other Specifications

Specifications for table size, wheel size, and other general machine data.

Identification of Machine Components

Section 1: Safety

General Safety Instructions

Essential safety warnings and guidelines for operating machinery.

Additional Safety for Metal Cutting Bandsaws

Specific safety precautions tailored for metal cutting bandsaw use.

Section 2: Circuit Requirements

Electrical Connection and Safety

Guidelines for power connection, voltage selection, and electrical safety.

Section 3: Set Up

Initial Setup and Safety Procedures

Covers setup safety, required items, unpacking, and initial inventory.

Inventory and Parts Check

Lists components and hardware included with the machine for inventory.

Cleaning and Site Preparation

Instructions for cleaning the machine and choosing a suitable operating location.

Cabinet, Wheels, and Feet Assembly

Steps for assembling the cabinet base, wheels, and rubber feet.

Shipping Strap and Vise Alignment

Procedures for removing shipping restraints and squaring the vise.

Chip Tray and Auto Shut-Off Setup

Installing the chip tray and setting the automatic shut-off lever.

Pulley Cover Installation

Steps for correctly installing the pulley cover for safe operation.

Test Run Procedure

Recommended Adjustments Verification

Section 4: Operations

Operational Safety Guidelines

Safety rules and precautions to follow during machine operation.

Blade Speed Selection and Adjustment

How to choose and change blade speeds for different materials.

Blade Selection Guide

Chart and rules for choosing the correct bandsaw blade for materials.

Feed Rate Control

How to adjust the feed rate for optimal cutting performance.

Blade Guide Adjustment

Steps for properly aligning and adjusting the blade guides.

Blade Tensioning

Importance and procedure for setting correct blade tension.

Operation Tips and Best Practices

Advice for safe and efficient bandsaw operation and blade longevity.

Section 5: Accessories

Section 6: Maintenance

Maintenance Schedule

Recommended checks and tasks for daily, monthly, and annual maintenance.

Cleaning Procedures

How to clean the bandsaw to maintain performance and longevity.

Lubrication Points and Schedule

Locations and frequency for lubricating machine parts for optimal function.

Section 7: Service

Troubleshooting Common Issues

Solutions for problems related to motor, electrical, and operational issues.

Blade Change Procedure

Step-by-step guide for safely replacing the bandsaw blade.

Blade Tracking Adjustment

How to adjust the blade tracking for proper wheel alignment.

Electrical Components Overview

Identification and images of key electrical parts like the capacitor.

Wiring Diagram and Connections

Schematic showing 110V and 220V wiring configurations.

Saw Parts Breakdown

Stand Parts Breakdown

Guides & Shafts Parts Breakdown

Labels Parts Breakdown

Warranty Card

Warranty and Returns Policy

Grizzly G9742 Specifications
