Sanding Belt Drive System Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
301 P9983301 CONTACT ROLLER BASE 342 PR11M EXT RETAINING RING 25MM
302 PLW06M LOCK WASHER 10MM 343 PR25M INT RETAINING RING 47MM
303 PCAP72M CAP SCREW M10-1.5 X 30 344 P6005ZZ BALL BEARING 6005ZZ
304 P9983304 SWITCH PLATE 345A P9983345A CONTACT ROLLER ASSEMBLY
305 PW04M FLAT WASHER 10MM 346 P9983346 ROLLER SHAFT
306 PLW06M LOCK WASHER 10MM 347 P9983347 SLEEVE
307 PCAP72M CAP SCREW M10-1.5 X 30 348 PR11M EXT RETAINING RING 25MM
308 P9983308 COVER 349 PR25M INT RETAINING RING 47MM
309 PS02M PHLP HD SCR M4-.7 X 12 350 P6005ZZ BALL BEARING 6005ZZ
310 PLW04M LOCK WASHER 8MM 351 P9983351 SUPPORT ROLLER
311 PB07M HEX BOLT M8-1.25 X 25 352 P9983352 ROLLER SHAFT
312 P9983312 FORK 353 P9983353 BUSHING
313 PW03M FLAT WASHER 6MM 354 P9983354 ROLLER BASE
314 PS14M PHLP HD SCR M6-1 X 12 355 P9983355 MICROMETER BASE
315 P9983315 CYLINDER ROLLER FRAME 356 PCAP26M CAP SCREW M6-1 X 12
316 PSS04M SET SCREW M6-1 X 12 357 P9983357 MICROMETER
317 P9983317 SUPPORT TUBE 358 PSS04M SET SCREW M6-1 X 12
318 PLW04M LOCK WASHER 8MM 359 P9983359 MAIN WORM GEAR SHAFT
319 PCAP76M CAP SCREW M8-1.25 X 18 360 P9983360 CONNECTION COUPLING
320 P9983320 TOP ROLLER SUPPORT LH 361 PSS04M SET SCREW M6-1 X 12
321 PLW04M LOCK WASHER 8MM 362 P9983362 SUPPORT WORM GEAR SHAFT
322 PCAP76M CAP SCREW M8-1.25 X 18 363 P9983363 GRAPHITE BASE LH
323 P9983323 TOP ROLLER SUPPORT RH 364 P9983364 GRAPHITE BASE RH
324 PSS04M SET SCREW M6-1 X 12 365 P9983365 WORM GEAR
325 P9983325 KNOB BOLT M8-1.25 X 80 366 P9983366 GEAR BUSHING
326 P9983326 ECCENTRIC SHAFT 367 PLW04M LOCK WASHER 8MM
327 PR11M EXT RETAINING RING 25MM 368 PB03M HEX BOLT M8-1.25 X 16
328 P6205ZZ BALL BEARING 6205ZZ 369 P9983369 VERT MICROMETER SCREW M18-2.8 & M10-1.5
329 P9983329 TOP ROLLER 370 P9983370 PLATEN (MALE)
330 P9983330 TOP ROLLER SHAFT 371 PW01M FLAT WASHER 8MM
331 P9983331 TOP COVER 372 PCAP58M CAP SCREW M8-1.25 X 12
332 P99796315 GASKET 373 P9983373 PLATEN (FEMALE)
333 PFH02M FLAT HD SCR M6-1 X 12 374 P9983374 GRAPHITE CLOTH 3-3/8"W X 16-1/4"L
334 P9983334 SPRING COVER 375 P9983375 SET PLATE
335 P9983335 SHAFT 376 PW05M FLAT WASHER 4MM
336 P9983336 COMPRESSION SPRING D25 X 24 377 PS02M PHLP HD SCR M4-.7 X 12
337 P9983337 BOTTOM COVER 378 P9983378 LINING
338 PS06M PHLP HD SCR M5-.8 X 20 379 PLW07M LOCK WASHER 20MM
339 PR05M EXT RETAINING RING 15MM 380 PN17M HEX NUT M20-1.5
340 PN02M HEX NUT M10-1.5 381 P9983381 SANDING BELT #180 16 X 48"
341 P9983341 OSCILLATION SQUARE 381-1 P9983381-1 SANDING BELT #240 16 X 48"
