Groen Eclipse BPM-30G User Manual

OM/SM-BPM-G 27
13 15 BURNER ORIFICE, 40 GALLON-NATURAL GAS
13 15 BURNER ORIFICE, 40 GALLON-PROPANE
Combustion Chamber and Gas Manifold Assemblies Parts List
KEY QTY COMBUSTION CHAMBER & GAS MANIFOLD ASSEMBLIES
1 1 COMBUSTION CHAMBER ASSY, 30 GALLON 145941
1 1 COMBUSTION CHAMBER ASSY, 40 GALLON 144843
2 1 MANIFOLD, 30 GALLON 145944
2 1 MANIFOLD, 40 GALLON 144845
3 1 PILOT BURNER W/O PILOT ORIFICE, ELECTRONIC IGNITION ONLY
3 1 PILOT ORIFICE, ELECTRONIC IGNITION-NATURAL GAS 119449
3 1 PILOT ORIFICE, ELECTRONIC IGNITION-PROPANE 098647
4 1 MOUNTING BRACKET FOR PILOT 119418
5 11 BURNER TUBE, 30 GALLON 144847
5 15 BURNER TUBE, 40 GALLON 144847
6 21 NUT, KEPS 1/4-20 012940
7 1 IGNITION TUBE, 30 GALLON 145957
7 1 IGNITION TUBE, 40 GALLON 145912
8 1
IGNITION TUBE ORIFICE, -30 GALLON-NATURAL GAS 056932
8 1 IGNITION TUBE ORIFICE, -30 GALLON-PROPANE 112603
8 1 IGNITION TUBE ORIFICE, -40 GALLON-NATURAL GAS 101622
8 1 IGNITION TUBE ORIFICE, -40 GALLON-PROPANE 101665
9 2 SCREW, #10-32 X 1" 093478
10 2 IGNITION TUBE CLAMP 085107
11 2 NUT, KEPS 10-32 071256
12 3 SCREW, ROUND HEAD 1/4"-20 X 1" 012847
13 11 BURNER ORIFICE, 30 GALLON-NATURAL GAS 128158
13 11 BURNER ORIFICE, 30 GALLON-PROPANE 146148
128158
146148
1
1
146116
144833
28
RADIATION SHIELD WELDMENT, 30 GALLON (not shown)
RADIATION SHIELD WELDMENT, 40 GALLON (not shown)
097024
