Electrical Control Components-Gas Parts List
ELECTRICAL CONTROL COMPONENTS-GAS
1 1
KEY QTY PART #
FUSE HOLDER MAIN CONTROLS-ELECTRONIC IGNITION ONLY
077854
2 1
FUSE -24VAC CONTROL, 3A, TYPE AG-ELECTRONIC IGNITION ONLY
077853
3 1
SCREW, ROUND HEAD #8-32 X 1-1/4"-ELECTRONIC IGNITION ONLY
005056
4 3
SCREW, ROUND HEAD #6-32 X 3/8"
009697
5 4
SCREW, HEX SLOTTED HD #8-32 X 3/8"-ELECTRONIC IGNITION ONLY
006979
6 1
TILT SWITCH BRACKET WELD ASSY.-ELECTRONIC IGNITION ONLY
145689
7 1
BARRIER INSULATION-ELECTRONIC IGNITION ONLY
003490
8 1
TILT LIMIT SWITCH (HEAT CUT-OFF)-ELECTRONIC IGNITION ONLY
002982
9 1
POWER SWITCH -ELECTRONIC IGNITION ONLY
122004
10 1
LIGHT, INDICATOR AMBER 24V AC-ELECTRONIC IGNITION ONLY
116384
11 2
LAMP GASKET-ELECTRONIC IGNITION ONLY
137434
12 2
SCREW, ROUND HEAD #4-40 X 3/4"
003122
13 2
NUT HEXAGON #4-40
003121
14 2
WASHER, #6 INTERNAL TOOTH
013418
15 1
GROUND LUG-ELECTRONIC IGNITION ONLY
119829
16 1
TERMINAL BLOCK BOX BOTTOM-ELECTRONIC IGNITION ONLY
160801
17 1
TERMINAL BLOCK BOX-ELECTRONIC IGNITION ONLY
146205
18 6
SCREW, HEX SLOTTED-ELECTRONIC IGNITION ONLY
069773
19 1
TRANSFORMER [120/24 VAC, 20VA]-ELECTRONIC IGNITION ONLY
148899
20 1
TERMINAL BLOCK [2-POLE]-ELECTRONIC IGNITION ONLY
003887
21 1
LIGHT INDICATOR RED - 2aVAC
116383
22 3 FT
SLEEVING SIZE 7/16"-ELECTRONIC IGNITION ONLY (NOT SHOWN)
003874
23 2
ELBOW 90 DEG 3/8"-ELECTRONIC IGNITION ONLY (NOT SHOWN)
004098
24 6 IN
CONDUIT FLEXIBLE (NOT SHOWN)
006940
25 3
CONDUIT CLAMP 3/8"-ELECTRONIC IGNITION ONLY (NOT SHOWN)
008224
26 1
WIRE HARNESS,CONTROL LOW VOLTAGE BPM-30,40G-ELECTRONIC IGNITION
ONLY (NOT SHOWN)
160836
27 1
WIRING HARNESS POWER HIGH VOLTAGE BPM-30,40G-ELECTRONIC IGNITION
ONLY (NOT SHOWN)
160837
28 2
NUT LOCK 1/2" (NOT SHOWN)
005487
29 2
ELBOW 90 DEG 3/8"-ELECTRONIC IGNITION ONLY (NOT SHOWN)
004098
30 6
INSULATOR CONDUIT-ELECTRONIC IGNITION ONLY (NOT SHOWN)
071934
32 1
NUT, DOME #10-32 (NOT SHOWN)
128756
33 1
SCREW, HEX HD CAP #10-32 X 1/2" (NOT SHOWN)
128757
34 1
HIGH LIMIT THERMOSTAT (GAS) (NOT SHOWN)
119464
35 1
SPARK IGNITION MODULE-ELECTRONIC IGNITION ONLY (NOT SHOWN)
1 4 5
36 1
CONTROL THERMOSTAT (GAS), 100-450 (NOT SHOWN)
041700
37 1
THERMOSTAT KNOB (NOT SHOWN)
160825
38 1
THERMOSTAT GASKET (NOT SHOWN)
123585
39 1
THERMOSTAT ADAPTER (NOT SHOWN)
107172
40 1
ELECTRICAL PANEL COVER ASSEMBLY-ELECTRONIC IGNITION ONLY-MANUAL
TILT
160804
43 1
GAS CONTROL VALVE-ELECTRONIC IGNITION-NATURAL GAS (NOT SHOWN)
098443
43 1
GAS CONTROL VALVE-ELECTRONIC IGNITION-PROPANE (NOT SHOWN)
098444
41 1
EQUI POTENTIAL ASSY
122021
30
5 0 9
