Groen EE-20 User Manual

OM/SM-EE-CE 17
Cover Parts
1 ¼”-20 Nut, Dome 090567
2 Handle (20 & 40 Gallon) 047550
2 Handle (60 & 80 Gallon) 047552
3 Knob (Friction) 012691
4 Spacer 012733
58 Bracket, Hinge Cover (20 & 40 Gal.) 013485
59 Hinge Bar (20 & 40 Gal.) 061012
6 Actuator Cover (60 Gal.) 065901
7 Actuator Assembly (80 Gal.) MS12521
38 Tolerance Ring 012692
Valve Parts (Draw Off & Ball) & Strainer
20 2” Draw-Off Valve, Complete 009046
21 Valve Stem - 2” 009048
22 Rubber “O” Ring 009034
23 Sanitary Hex. Nut #13H - 2” 009354
24 Valve Handle 009029
25 Wing Nut 009028
61 Bonnet, Valve - 2” 009047
19 2” Ball Valve, Complete 110962
Valve Body - 2” Ball Valve 110927
-
- Valve Cover - 2” Ball Valve 110916
- Ball - 2” Ball Valve 110446
- Cavity Filler Seal - 2” Ball Valve 110443
- Actuating Shaft - 2” Ball Valve 110958
- Bushing, Shaft - 2” Ball Valve 110445
- Retaining Nut - 2” Ball Valve 110444
O-Ring, 0.070” Cross Section - 2” 110954
- Ball Valve
- Wing Nut - 1/4” - 2” Ball Valve 110953
- Wing Nut - 3/8” - 2” Ball Valve 052318
- Handle - 2” Ball Valve 110458
- 2” Sanitary Clamp 053786
- Gasket for 2” Sanitary Clamp 016602
40 Removable Strainer 9” Dia 1/4” 009044
holes, 2” Tangent Draw-Off
41 Removable Strainer 9” Dia 1/8” 013785
holes, 2” Tangent Draw-Off
42 Removable Strainer 9” Dia no holes, 013783
2” Tangent Draw-Off
Electrical Parts
43 Heater Element 240V-4000W 008851
43 Heater Element 2008V-3000W 008852
48 Power Light 116383
49 Heat Light 116384
50 Low Water Light 116384
51 Power Switch 146631
55 Boot, Power Switch 146632
52 Equipotential Terminal Assembly 122021
53 Water Level Control Board Assy 148323
56 Gasket, Lamp (3 used) 137434
16 Thermostat Kit 101542
17 Pressure Limit Control 108559
5 Fuse Holder 077854
13 Fuse - 3 Amp 077853
68 Terminal Block 088214
57 Ground Lug 129714
14 Contactor (20 Gal-[1], 40 Gal[2]) 121755
63 Transformer, 24 V Sec. 148899
64 Bracket, Electrical Component Mtg. 148171
65 Radiation Shield 127684
- Wiring Harness - Heater (20 Gal-[1], 145283
40 Gal [2])
- Wiring Harness - Control - 20 Gal 145281
- Wiring Harnes - Control - 40 Gal 148295
- Wiring Harness - Power 20 Gal 148167
- Wiring Harness - Power - 40 Gal 145282
Other Hardware
11 Valve Safety, 30 psig, PED 141361
12 Pressure Gauge 099156
15 Safety Valve & Waterfill Assy 143844
18 Thermostat Knob 122000
26 Connector Elbow 061163
27 Gauge Glass Gasket 008917
30 Water Gauge Glass 008742
31 Electrode - Water Level 074665
34 Foot Bullet Adjustable 013275
60 Water Fill Assembly 097007
62 Overlay, EE-20 132056
62 Overlay, EE-40 & 60 122036
66 Panel Assembly, Control Box 146666
67 Panel Assembly, Instrument Box 146665
EE (CE) SERVICE PARTS FOR 2005 MANUAL
10.0 Parts List
(Keyed to Drawings and Photographs on the Following Pages)
To order parts, contact your Groen Certified Service Agency. Supply the model designation, part description,
part number, quantity and, where applicable, voltage and phase.
Key Description Part No. Key Description Part No.
OM/SM-EE(CE)
17
