2.0 Inspection & Unpacking
The unit will arrive in a heavy shipping carton and
will be banded to a skid. Immediately upon receipt,
inspect the carton carefully for exterior damage.
Carefully cut any polyester straps around the carton
and detach the sides of the box from the skid. Pull
the carton up off the unit.
Thoroughly inspect the unit for concealed damage.
Report any shipping damage or incorrect shipments
to the delivery agent.
Write down the model number, serial number, and
installation date, and retain this information for future
reference. Space for these entries is provided at the
top of the Service Log at the back of this manual.
Keep this manual on file and available for operators
to use.
When installation is to begin, carefully cut any straps
which hold the unit on the skid.. Lift the unit straight
up off the skid. Examine packing materials to be sure
that loose parts are not discarded with the materials.
CAUTION
SHIPPING STRAPS ARE UNDER TENSION
AND CAN SNAP BACK WHEN CUT. TAKE
CARE TO AVOID PERSONAL INJURY OR
DAMAGE TO THE UNIT BY STAPLES LEFT
IN THE WALLS OF THE CARTON.
CAUTION
THIS UNIT IS VERY HEAVY. INSTALLER
SHOULD OBTAIN HELP AS NEEDED TO
LIFT THIS WEIGHT SAFELY.
The unit will arrive in a heavy carton. Inside it will be banded to a skid.
KETTLE CHARACTERISTICS
EE-20 EE-40 EE-60 EE-80
Capacity
20 gal (75 l) 40 gal (150 l) 60 gal (226 l) 80 gal (300 l)
Diameter
26 in (66 cm) 32 in (81 cm) 36 in (91 cm) 38 in (96.5 cm)
Rim Height
37 in (94 cm) 37 in (94 cm) 40 in (102 cm) 44 in (112 cm)
Total Width
26 in (66 cm) 32 in (81 cm) 36 in (91 cm) 38 in (96.5 cm)
Front to Back
38
1
/
4
in (97 cm) 48
1
/
4
in (123 cm) 47
1
/
4
in (120 cm) 49
1
/
4
in (125 cm)
