WARNING
GROUNDING INSTRUCTIONS: THIS APPLIANCE MUST BE CONNECTED TO A GROUNDED
METALLIC, PERMANENT WIRING SYSTEM, OR AN EQUIPMENT GROUNDING
CONDUCTOR MUST BE RUN WITH THE CIRCUIT CONDUCTORS AND CONNECTED TO
THE EQUIPMENT GROUNDING TERMINAL ON THE STATION.
Installation and Start-Up
CAUTION
DO NOT INSTALL THE UNIT WITHIN 2 INCHES OF A HEAT SOURCE (SUCH AS A BRAISING PAN, DEEP FAT
FRYER, CHARBROILER OR KETTLE).
Electrical Supply Connection - Observe all local, national, or other applicable codes.
Three phase models of the
Vortex™ Connectionless
St
eamer are supplied with a cord set ready to be
connected to a power supply. See the chart below
for the correct matching receptacle (not supplied with
the unit).
Single phase models are designed to be directly
connected (hard wired) to the electrical supply and
all
ow sufficient loop in the flexible conduit to facilitate
inspection, servicing, and cleaning.
Branch Circuit Protection
Each Steamer, including individual units of stacked
models, should have its own branch circuit protection
and ground wire. Current and power demands for
each unit are as shown below
.
ELECTRICAL SUPPLY CONNECTIONS
FIELD WIRING TABLE - USE COPPER WIRE ONLY - INSULATION RATING (90ºC)
VOLTAGE
(60 Hz Only)
KW
RATED CURRENT DEMAND
VRC-3E VRC-6E VRC-3E VRC-6E
20
8 3 PHASE 9KW 10KW 25 Amps 28 Amps
24
0 3 PHASE 9KW 10KW 22 Amps 25 Amps
48
0 3 PHASE 9KW 10KW 11 Amps 13 Amps
PLUG
AND RECEPTACLE CHART
VOLTS PHASE PLUG RECEPTACLE
9K
W 10KW 9KW 10KW
208 3 15-30P 15-50P 15-30R 15-50R
240 3 15-30P 15-50P 15-30R 15-50R
480 3 L16-30P L16-30P L16-30R L16-30R
208 1 ---- ---- ---- ----
240 1 ---- ---- ---- ----
