Toughsat Users Manual Ground Control
- 38 -
Toughsat Specifications
BANDWIDTH & NETWORK (iDirect Services- Galaxy 18)
Download (with 4 Watt BUC)............................................ Up to 3000 Kbps (5000 Kbps with 6 Watt BUC)
Upload (with 4 Watt BUC) ............................................... Up to 1000 Kbps (2000 Kbps with 6 Watt BUC)
Public IP Address............................................................. Included
DHCP................................................................................ Yes. Wireless or 4 port Ethernet
Wireless Security...............................................................WPA (TKIP) WPA2 (AES) + WEP 64 and 128bit
NAT................................................................................... Supported by included router
Firewall............................................................................. Supported by included router
Port Mapping & Port Triggers........................................... Supported by included router
QoS, ToS, MAC Address Clone, RIP v1 RIP v2............... Supported by included router
Networkable clients machines.......................................... Unlimited
Wi-Fi................................................................................. Cisco Linksys wireless router “G”
SATELLITE DISH
Reflector Type …………………………………………….. 0.98 square meter effective area
Mount Geometry…………………………………………….. 3 Axis motor drive (elevation, azimuth & skew)
Deployment Sensors ………………………………………..GPS & Tilt Sensor +- 1°
MAXIMUM MOUNT ROTATION
Azimuth………………………………………………………..410°
Elevation………………………………………………………165°
Polarization……………………………………………………+-80°
RF INTERFACE
Transmit Power………………………………………………4 watts for XP, 3 Watts for SP (Upgradable to 6 Watt)
Receive Frequency………………………………………….Range 950-1450 mhz
DIMENSIONS OF DISH
Dish Stowing Extended Dimensions ………………………59" L x 39” W x 12” H (150 x 74 x 30.5 cm)
Mounting Plate………………………………………………..22” x 57” ( 56 x 145 cm)
Base Plate (attached to mounting plate)…………………..14” x 16” (35.6 x 40.7 cm)
Deployed Height……………………………………………...52” max height (132 cm)
Weight…………………………………………………………125 lbs (56.7 kg)
Boom Sweep………………………………………………….53” from center (Clearance is 15” for most locations)
ENVIRONMENT
Wind Deployed……………………………………………….75 mph (120 kph)
Wind Stowed………………………………………………….140 mph (225 kph)
Max Operational Temperature (at 100% humidity)……….Operational -20° F to 140° F (-28° C to 60° C)
Max Survival Temperature (at 100% humidity)……………-60° F to 160° F (-51° C to 71° C)
Power Requirements
Dish Controller & Dish Motors (Via 120 VAC).................. 15 watts average (can be turned off after pointing)
iDirect Modem (via AC120V to DC 24V @ 5 Amp).......... 75 watts average
