5.2. Selecting mounting location
This is guidance for installer to choose a suitable installation location, to avoid
potential damages to device and operators.
The installation location must be suitable for the inverter's weight and
dimensions for a long period time. (Refer to section 3.3)
Do not install the inverter on structures constructed of flammable or
thermolabile materials.
Never install the inverter in environment of little or no air flow, nor dust
environment. That may derate the efficiency of the cooling fan of the inverter.
The Ingress Protection rate is IP65 which means the inverter can be installed
outdoors and indoors.
Do not expose the inverter to direct sunlight, in order to avoid the power and
efficiency derating caused by excessive heating.
The humidity of the installation location should be 0~100% without
condensation.
The ambient temperature should be below 40℃ to ensure optimal operation.
The installation location must be freely and safely to get at all times.
Vertically installation and make sure the connection of inverter must be
downwards. Never install horizontal and avoids forward and sideways
tilt.(Refer to drawings below)
Do not install the inverter near television antenna or any other antennas and
antenna cables.
Do not install the inverter in living area, the noise caused by the machine
may affect on daily life.
For security reasons, don’t install the inverter in place where the children
can reach.
Don't put any things on the inverter.Do not cover the inverter.
Inverter requires adequate cooling space. Providing better ventilation for
the inverter to ensure the heat escape adequately.
Do not expose the inverter to direct sunlight, as this can cause excessive
heating and thus power reduction.
Observe the minimum clearances to walls, other inverters or objects as
shown in the diagram below in order to guarantee sufficient heat dissipation.
Ambient dimensions of one inverter
