Growatt 3000 User Manual

6.2.1. Country selecting
6.2. Independent function option
Country/Regulation Name
options
VDE0126-1-1 // 0
Germany //1
UK_G83 //2
Italy
//3
France
//4
Denmark
//5
Belgium
//6
Spain
//7
Greece //8
Turkey
//9
If the country you want to select is not in the above list, please
directly select VDE0126-1-1.
Netherlands select VDE0126-1-1.
NOTICE
Please finish the country selecting according to the following steps
A The LCD will quickly switch to and stay at the 'Please select' interface after
power on, as below:
B Single knock on the LCD, countries will vary from one to another along the
above list order. below acts as an example, and Germany is the second
selection.
C When you need to select any of these countries, you can Double knock to
enter the next interface. Here we select Italy as an example, as below:
D When the country arrives at Italy, Double knock to enter the two options 'YES'
and 'NO', and the cursor stays at 'NO' in default, as below:
E Single knock to select 'YES', as below:
F Double knock to confirm your selection, LCD will display 'Select OK' with the
country name in the below, as below:
28 29
Information
If you have ordered the inverter with specific country settings, the
parameters have been preset in factory and you don't need to
operate this step any more.
This series inverter in Hungary market has not country settings.
When the PV panels are connected and their output voltage is greater than 70Vdc
but the AC grid is not yet connected, inverter will start up automatically. If it is the
first time to power on the inverter after installation, you may need to select a
specific country.Otherwise, the interface will stay at the ‘Please Select’ interface
all the time. There are eleven options to select, as the list below.
