REF. NO. FROM EXPLODED VIEW DESCRIPTION QUANTITY
42 Washer 1
43 Connecting Rod 1
44 Slotted Spring Pin 3
45 Connector 1
46 Extension Rod 1
47 Steel Ball (7/32”) 2
48 Non Return Spring 2
49 Valve 1
50 O ring (BS812) 2
51 Pump Cylinder 1
52 Top Coupler 1
53 Slide Bush 1
54 Bottom Coupler 1
55 Piston Rod 1
56 Guide Bush 1
57 Filter Tube 1
58 Filter Washer 1
59 Filter Circlip 1
60 Piston Washer 1
61 Nyloc Nut 1
62 Filter Cap 1
63 Barrel 1
PARTS LIST FOR DRUM COVER, FOLLOWER PLATE,
HOSE, Z SWIVEL & GREASE CONTROL VALVE
REF. NO. FROM EXPLODED VIEW DESCRIPTION QUANTITY
64 Follower Plate 1
65 Drum Cover 1
66 Hose 1
67 Z Swivel 1
68 Grease Control Valve 1
Table 2
