19
MODEL GP1 GP2 GP3
Bucket Capacity 20-30 Kg / 5 Gal / 25-50 lbs. 50-60 Kg / 16 Gal / 120 lbs. 180 Kg / 55 Gal / 400 lbs.
Suction Tube Length 17.32” (440 mm) 28.74” (730 mm) 37.38” (950 mm)
Suction Tube Dia. 1.18” (30mm)
Flow Rate 1.10 Kg / min. (2.42 lbs / min)
Working Pressure 10 BAR (150 PSI)
Maximum Outlet Pressure 500 BAR (7500 PSI)
Air Inlet Connection 1/4” (F)
Pump Outlet Connection 1/4” (F)
Air Consumption 230 LPM (61 GPM)
Hose Length* 7’ (84”)
Noise Level 81 db
SPECIFICATIONS
• Always wear protection gear like safety goggles, gloves, apron, and ear plugs while operating the pump
• Never let any body part come in front of, or in contact with the control outlet
• Always cut off air supply after use, so that media cannot leak in case any of the pump component fails
• Before switching the air supply on, check hoses for sign of wear, leak or loose fittings. Replace as necessary
• Do not smoke near the pump. Do not use the pump near a source of spark / open flames
• When changing the working fluid, at least 1 litre of new fluid should be discarded to avoid mixing of fluids
• Pump should NOT be operated for more than 4 hrs continuously
• Pump must be supplied with CLEAN & DRY compressed air via an FRL unit
• Before attempting any repair of this product, disconnect air supply and then squeeze control valve trigger to release fluid pressure
• Use only genuine factory parts for repair
WETTED COMPONENTS
Steel, Brass, Aluminium, & Polyurethane
RECOMMENDED USE
With light and self collapsing grease up to NLGI No. 2
* IT MAY VARY FROM ONE MODEL TO ANOTHER
Table 7
