Grundfos DME 940 User Manual

7
English (US)
3.3 Identification
3.3.1 Type key
(Cannot be used for pump configuration.)
Code Example DME 60 - 10 AR - PP/ E/ C - F - 2 1 A3/A3 B
Pump range
Maximum capacity [l/h]:
60
150
375
940
Maximum pressure [bar]:
4
10
AR
AP
Control variant:
Standard
Standard + Profibus
PP
PV
SS
Dosing head material:
Polypropylene
PVDF
316 stainless steel
E
T
V
Gasket material:
EPDM
PTFE
FKM
C
G
SS
T
Y
Valve ball material:
Ceramics
Glass
316 stainless steel
PTFE (only 375 and 940)
Hastelloy
F
S
Control panel:
Front-fitted
Side-fitted
2
3
Voltage:
1 x 120 V, 60 Hz
1 x 100-240 V, 50/60 Hz
1
2
Valves:
Standard valve
Spring-loaded valve
A3
A4
Connection, suction/discharge:
3/4" FNPT
1 1/4" FNPT
B
Mains plug:
USA
