6.4 Suction heights
6.4.1 Media with a viscosity similar to water
Applies to:
• counter-pressure of 1.5 to 3 bar
• non-degassing and non-abrasive media
• temperature of 20 °C
• stroke length 100 %.
* Suction line and dosing head filled (continuous operation)
** Suction line and dosing head not filled, but dosing head and valves moistened (start-up)
Pump type
50 Hz 60 Hz
Maximum length of
suction line
[m]
Suction height*
[mWC]
Intake height**
[mWC]
Suction height*
[mWC]
Intake height**
[mWC]
DMX 4-10 4 4 4 4 5
DMX 7-10 4 4 4 4 5
DMX 9-10 3 3 3 3 4
DMX 12-1032.532.54
DMX 17-4 1 1 1 1 2
DMX 25-3 1 1 1 1 2
DMX 7.2-16 4 3 4 3 5
DMX 8-10 4 4 4 4 5
DMX 14-1043445
DMX 18-1033334
DMX 26-1032.532.54
DMX 39-4 1 1 1 1 2
DMX 60-3 1 1 1 1 2
DMX 13.7-16 4 3 3.5 2.5 5
DMX 16-10 4 3 3.5 2.5 5
DMX 27-10 4 3 3.5 2.5 5
DMX 35-10 3 2 2.5 2 4
DMX 50-10 3 2 2.5 1.5 4
DMX 75-4 1 1 0.5 0.5 2
DMX 115-3 1 1 0.5 0.5 2
