0: Invalid
1: In operation
2: Forward rotation operation
3: Reverse rotation operation
4: Jogging operation
5: The inverter fault
6: Frequency degree test FDT1
7: Frequency degree test FDT2
8: Frequency arrival
9: Zero speed running
10: Upper limit frequency arrival
11: Lower limit frequency arrival
12: Ready for operation
13: Pre-magnetizing
14: Overload pre-warning
15: Underload pre-warning
16: Completion of simple PLC stage
17: Completion of simple PLC cycle
18: Setting count value arrival
19: Defined count value arrival
20: External fault valid
21: Reserved
22: Running time arrival
23: MODBUS communication virtual terminals output
24–26: Reserved
27: Weak light
28: Switching to PV power frequency input (threshold-based)
29: Switching to PV power frequency input (S input-based)
30: Switching to power frequency (threshold- or S input-based)
Note: Function 30 is relay output combining the functions 29 and 28. When one of
the two conditions is met, the relay output frequency is high.
Used to set the parameter copying mode.
0: No operation
1: Upload function parameters from the pump controller to keypad
2: Download function parameters (including the motor parameters) from the
keypad to pump controller
3: Download function parameters (excluding motor parameters of the P02 group)
from the keypad to pump controller
4: Download function parameters (only motor parameters of the P02 group) from
the keypad to pump controller
Note:
After the parameter is set to 1, 2, 3 or 4, and the operation is executed, the parameter
is automatically restored to 0.
