4. Startup of the product
5.3 Intended use
5.5 Identification
5.5.1 Nameplate example for JP and JP Booster
Type: JP 5-48 PT-H No: 99XXXXXX P4 1825
Qmin: 1.2 m
3
/h Qmax: 4.8 m
3
/h IP: 44
Hmin: 25 m
Hmax: 48.3 m
Class: F
n: 2800 min-1
25 µF / 250 V ~
pmax: 0.6/6 Mpa/bar
Tmax amb: 40 ˚C S1 / 55 ˚C S3
Tmax liquid: 40 ˚C S1 / 60 ˚C S3
Serial nr. XXXXXX
P1: 1.45 kW / 1.95 HP
P2: 1.36 kW / 1.49 HP
U: 1x230 V~ 50 Hz
Made in Hungary by Grundfos
2
3
4
5
6
7
8 9
10
13
12
11
14
15
16171819
I1/1: 7.6 A
1
DK - 8850 Bjerringbro Denmark
TM072531
Pos. Description
1 Type
2 Min. flow rate and max. flow rate
3 Min. head and Max. head
4 Max. pressure
5 Supply voltage and Frequency
6 Full-load current
7 Approvals
8 Power consumption
9 Rated power
10 Country of origin
11 Capacitor data
12 Speed of rotation
13 Serial number
14 Insulation class
15 Enclosure class
16 Factory and production code, year and week
17 Product number
18 Max. ambient temperature
19 Max. liquid temperature
Related information
2.1 Inspecting the product
5.5.2
Type key, JP pump and booster
Example:
JP . 3- . 42 . PT- . V . 1x230 V . 50 Hz . 2m .
SCHUKO . HU
Description
JP Jet Pump
3-
Max. flow rate [m
3
/h]
42 Max. head [m]
PT-
Booster type, if applicable:
• PT: Pressure Tank
• PM: Pressure Manager
• PS: Pressure Switch
V
Tank type, if applicable:
• V: Vertical
• H: Horizontal
1x230 V Voltage [V]
50 Hz Frequency [Hz]
2m Cable length [m]
SCHUKO Plug type
HU Country of origin
6. Service
WARNING
Electric shock
Death or serious personal injury
‐ Switch off the power supply before you
start any work on the product. Make
sure that the power supply cannot be
switched on accidentally.
WARNING
Chemical hazard
Death or serious personal injury
‐ Make sure that the product has only
been used for water. If the product has
been used for pumping aggressive
liquids, flush the system with clean
water before you start work on the
product.
WARNING
Biological hazard
Death or serious personal injury
‐ Make sure that the product has only
been used for water. If the product has
been used for pumping aggressive
liquids, flush the system with clean
water before you start work on the
product.
16
English (GB)

Grundfos JP Specifications

General

Power supply	Electric
Material	Stainless Steel, Cast Iron
Applications	pressure boosting
Pump Type	Self-priming centrifugal pump
Horsepower	1.5 HP
Phase	Single-phase
Inlet Size	1 inch
Outlet Size	1 inch
