Grundfos JP User Manual

9.3 Inlet pressure
Max. inlet pressure
JP 3-42: 1.5 bar / 0.15 MPa
JP 4-47: 1.0 bar / 0.10 MPa
JP 4-54: 0.5 bar / 0.05 MPa
JP 5-48: 1.0 bar / 0.10 MPa
9.4 Miscellaneous data
Cut-in pressure
Preset cut-in pressure (start
pressure):
JP PM: 1.5 bar
JP PT-V: 2.2 bar
JP PT-H: 2.2 bar
Min./max. storage
temperature
-20/+70 °C
10. Disposing of the product
This product or parts of it must be disposed of in an
environmentally sound way.
1. Use the public or private waste collection
service.
2. If this is not possible, contact the nearest
Grundfos company or service workshop.
3. Dispose of the waste battery through the national
collective schemes. If in doubt, contact your local
Grundfos company.
The crossed-out wheelie bin symbol
on a product means that it must be
disposed of separately from
household waste. When a product
marked with this symbol reaches its
end of life, take it to a collection point
designated by the local waste
disposal authorities. The separate
collection and recycling of such
products will help protect the
environment and human health.
See also end-of-life information
at www.grundfos.com/product-recycling.
23
English (GB)

Grundfos JP Specifications

General

Power supply	Electric
Material	Stainless Steel, Cast Iron
Applications	pressure boosting
Pump Type	Self-priming centrifugal pump
Horsepower	1.5 HP
Phase	Single-phase
Inlet Size	1 inch
Outlet Size	1 inch
