11
3. Fit the module.
!
TM02 0241 0904
"
TM02 0242 0904
#
TM02 0805 0904
4. Connect the relevant cables.
Examples of cable connections can be found on pages 103 to 106.
Cable specifications are stated in section 8. Technical data.
5.
Switch on the electricity supply.
