Grundfos Magna Installation And Operating Instruction

10
7. Fitting the module
1. Switch off the electricity supply by means of the external mains switch.
2. Open the terminal box cover and remove the label “MODULE”.
!
"
TM02 0457 3503 TM02 0456 3503

Grundfos Magna Specifications

General

Frequency	50/60 Hz
Temperature Range	-10 °C to +110 °C
Type	Circulator Pump
Maximum Operating Pressure	10 bar
Insulation Class	F
Series	Magna
Material	Cast iron
Voltage	1 x 230 V / 3 x 400 V (depending on model)
