Grundfos MAGNA1 Safety Instructions And Other Important Information

3
English (US)
2. Type key
Code Example MAGNA1 (D) 100 -120 (F) 360
Type range
MAGNA1
D
Single-head pump
Twin-head pump
Nominal diameter (DN) of suction and discharge ports [mm]
Maximum head [dm]
F
Pipe connection
Threaded
Flange
Port-to-port length [mm]

Grundfos MAGNA1 Specifications

General

Pump Type	Circulator Pump
Flow Range	0.5 - 12 m³/h
Maximum Flow	12 m³/h
Maximum Head	10 m
Maximum Liquid Temperature	110°C
Maximum Operating Pressure	10 bar
Power Supply	230 V, 50/60 Hz
Enclosure Class	IP42
Insulation Class	F
Pump Housing	Cast Iron
Installation Length	180 mm
Series	MAGNA1
Energy Efficiency Class	A
Liquid Temperature Range	2°C to 110°C
Approvals	CE, EAC
Ambient Temperature Range	0 .. 40 °C
