Grundfos magna3 Instructions

English (GB)
10
WARNING
Electric shock
Death or serious personal injury
- Connect the pump to an
external main switch with a
minimum contact gap of 3 mm in
all poles.
- Use earthing or neutralisation
for protection against indirect
contact.
- If a plug-connected pump is
connected to an electric
installation where an electrical
circuit breaker (voltage sensing
ELCB, residual-current device
RCD or residual-current circuit
device RCCB) is used as an
additional protection, this circuit
breaker must be marked with
the first or both of the symbols
shown below.
If the pump is
terminal-connected, the circuit
breaker must be marked with
both of the symbols below.

Grundfos magna3 Specifications

General

Liquid Temperature Range	-10°C to +110°C
Max Operating Pressure	16 bar
Type	Circulator Pump
Series	MAGNA3
Operating Temperature Range	-10°C to +110°C
Ambient Temperature Range	0°C to +40°C
Protection Class	IPX4D
Power Supply	1 x 230 V, 3 x 230 V, 3 x 400 V
Control Mode	Constant pressure, Proportional pressure
Communication	Modbus RTU
Pump Housing	Cast Iron
Impeller	Composite
Enclosure Class	X4D
Approvals	CE, EAC
Connection	Flange
Weight	Varies depending on model
Power Consumption	Varies depending on model
