Grundfos magna3 Instructions

English (GB)
13
Setting the product
WARNING
Electric shock
Death or serious personal injury
- Separate input voltages from
external equipment from live parts
by reinforced insulation.
CAUTION
Hot surface
Minor or moderate personal injury
- At high liquid temperatures, the
pump housing may be so hot that
only the control panel should be
touched to avoid burns.
Set the operating mode to "Normal"
before you enable a control mode.

Grundfos magna3 Specifications

General

Liquid Temperature Range	-10°C to +110°C
Max Operating Pressure	16 bar
Type	Circulator Pump
Series	MAGNA3
Operating Temperature Range	-10°C to +110°C
Ambient Temperature Range	0°C to +40°C
Protection Class	IPX4D
Power Supply	1 x 230 V, 3 x 230 V, 3 x 400 V
Control Mode	Constant pressure, Proportional pressure
Communication	Modbus RTU
Pump Housing	Cast Iron
Impeller	Composite
Enclosure Class	X4D
Approvals	CE, EAC
Connection	Flange
Weight	Varies depending on model
Power Consumption	Varies depending on model
