Grundfos SCALA2 Instructions

8. Handling and storing the product
8.1 Handling the product
Take care not to drop the pump as it may break.
8.2 Storing the product
If the pump is to be stored for a period of time, for example during
the winter, drain it and store it indoors in a dry location.
Temperature range during storing must be -40 to +70 °C (-40 to
+158 °F).
Maximum relative humidity during storing 95 % RH
Related information
12. Starting up the product after standstill
9. Control functions
9.1 Menu overview, SCALA2
TM063301
SCALA2 operating panel
SCALA2 Function
On/off
Increases the outlet pressure.
Decreases the outlet pressure.
Resets alarms.
Indicates the required outlet pressure.
Indicates that the pump has been stopped manually.
Indicates that the operating panel is locked.
15
English (GB)

Grundfos SCALA2 Specifications

General

Max Inlet Pressure	6 bar
Pumped Liquid	Clean water
Maximum Operating Pressure	10 bar
Installation	Indoor
Mains Frequency	50/60 Hz
Connection Size	1 inch
Pump Type	Self-priming, centrifugal pump
Max Flow	3 m³/h
Power Supply	1 x 200-240 V
Power Consumption	550 W
Liquid Temperature Range	0°C to +45°C
Protection Class	X4D
Weight	10 kg
Approvals	CE, EAC
Maximum Ambient Temperature	+55°C
Type of Inlet Connection	G 1 inch
Type of Outlet Connection	G 1 inch
Material	Stainless steel
