8.9 Service kits
The following service kits are available for all pumps.
* For pumps produced in week 19, 2014: P.C. code 1419.
Service kit Contents Pump type Material Product number
Shaft seal kit Shaft seal complete
SEG.40
09-15
NBR 96076122
SEG.50 NBR 96076123
SEG.40
26-40
FKM 96645160
SEG.50 FKM 96645275
Shaft seal
carrier
Shaft seal carrier SEG.50 99346051
Shaft with rotor Shaft with rotor complete SEG.50
26 99346054
26...Ex 99346055
31-40 99346058
31-40...Ex 99346091
O-ring kit
O-rings and gaskets for oil
screws
SEG40/50
09-15 NBR
96076124
98682327*
09-15 FKM
96646061
98682329*
26-40 NBR 96076125
26-40 FKM 96646062
Grinder system
Grinder head, grinder ring,
locking screw, and washer
SEG.40
Standard 96076121
Heavy duty 96903344
SEG.50 High flow 98453210
Impeller
Impeller complete with
adjusting nut, shaft screw
and key
SEG.40
09 96076115
12 96076116
15 96076117
26 96076118
31 96076119
40 96076120
SEG.50
26 99346032
31 99346046
40 99346048
Oil
1 litre of oil, type Shell
Ondina X420.
See section 8.4 Oil check
and oil change for required
quantity in oil chamber.
All types 96586753
Lifting bracket Lifting bracket and screw SEG.40/50
09-15 96690420
26-40 96690428

Grundfos SEG Series Specifications

General

Power Supply	Electric
Maximum Liquid Temperature	40°C
Installation	Submersible
Protection Class	IP68
Applications	Sewage, wastewater
Material	Cast iron
Impeller Type	Vortex
Frequency	50 Hz
Housing Material	Cast iron
Impeller Material	Cast iron
Seal Type	Mechanical seal
Weight	Varies depending on model (typically 30-60 kg)
