English (GB)
16
6. Product introduction
6.1 Product description
Fig. 12 SE pump
6.2 Applications
The SE1 and SEV pumps are designed for handling
wastewater, process water and unscreened raw
sewage in heavy-duty municipal, utility and industrial
applications.
The pumps are available with the efficient S-tube
®
or
SuperVortex impellers allowing for free passage of
solids up to 100 mm.
The pumps can be used in permanent, dry
installations or in submerged installations on auto-
coupling systems. The pumps are also suitable for
free-standing installations or as portable pumps.
6.3 Pumped liquids
The standard cast iron versions are designed for
pumping these liquids:
• large quantities of drainage, surface and storm
water
• domestic wastewater with discharge from toilets
• wastewater with a high content of fibres
(SuperVortex impeller)
• industrial process water
• wastewater with gaseous sludge
• municipal and commercial sewage and
wastewater.
Stainless steel versions
The stainless steel versions are suitable for pumping
the following liquids:
• industrial process water containing chemicals
• aggressive or corrosive drain water and effluent
• wastewater with abrasive particles
• wastewater contaminated with seawater.
6.4 Potentially explosive environments
Use explosion-proof pumps for applications in
potentially explosive environments. See section
6.7 Approvals.
TM06 5987 0216
Pos. Description
1 Lifting bracket
2Nameplate
3 Sleeve
4Oil screw
5 Outlet flange
6 Outlet opening
7 Cable plug
8 Top cover
9 Clamp
10 Pump housing
5
6
1
2
3
4
7
9
10
8
SE1 and SEV pumps must under no
circumstances pump combustible liquids.
The classification of the installation site
must be defined by the owner of the site in
each individual case.
