English (GB)
11
1)
The maximum stroke frequency varies depending on calibration
2)
Data is based on measurements with water
3)
Maximum suction lift: 1 m, dosing capacity reduced (approx. 30 %)
4)
Length of inlet line: 1.5 m, length of outlet line: 10 m (at max. viscosity)
5)
FS = Full-scale (maximum actual dosing flow), SP = Setpoint
6)
For FCM control variant and for pumps with diaphragm leakage detection the pressure difference must be
at least 2 bar / 29 psi.
Electrical data
Voltage [V] 100-240 V ± 10 %, 50/60 Hz
Length of mains cable [m] 1.5
Max. inrush current for 2 ms (100 V) [A] 35
Max. inrush current for 2 ms (240 V) [A] 70
Max. power consumption P
1
[W] 62
Enclosure class IP65, Nema 4X
Electrical safety class I
Pollution degree 2
Signal input
Max. load for level input 12 V, 5 mA
Max. load for pulse input 12 V, 5 mA
Max. load for External stop input 12 V, 5 mA
Min. pulse length [ms] 5
Max. pulse frequency [Hz] 100
Impedance at 0/4-20 mA analog input [Ω]15
Accuracy of analog input (full-scale value) [%] ± 0.5
Min. resolution of analog input [mA] 0.02
Max. loop resistance in external circuit [Ω] 150
Signal output
Max. resistive load on relay output [A] 0.5
Max. voltage on relay/analog output [V] 30 VDC / 30 VAC
Max. loop resistance in external circuit of the
0/4-20 mA analog output
[Ω] 500
Accuracy of analog output (full-scale value) [%] ± 0.5
Min. resolution of analog output [mA] 0.02
Weight/size
Weight (PVC, PVDF) [kg] 6.7 7.9 8.9
Weight (stainless steel) [kg] 7.2 8.3 9.1
Diaphragm diameter [mm] 74 97 117
Sound
pressure
Max. sound pressure level [dB(A)] 80
Approvals CE, CSA-US, NSF61, EAC, ACS, RCM
Data 60-10 120-7 200-4
