English (GB)
8
3.5 Type key
The type key is used to identify the precise pump
and is not used for configuration purposes.
Example: DDA 60-10 FCM-PVC/V/C-F-31U3U3FG
Type
DDA 60-10 FCM-PVC/V/C-F-31U3U3FG
Max. flow [l/h]
DDA 60-10 FCM-PVC/V/C-F-31U3U3FG
Max. pressure [bar]
DDA 60-10 FCM-PVC/V/C-F-31U3U3FG
Control variant
DDA 60-10 FCM-PVC/V/C-F-31U3U3FG
AR Alarm relay
FCM AR + FlowControl function
Dosing head variant
DDA 60-10 FCM-PVC/V/C-F-31U3U3FG
PVC Polyvinyl chloride
PV PVDF
SS Stainless steel 1.4401
PVC-L
PVC + integrated diaphragm leakage
detection
PV-L
PV + integrated diaphragm leakage
detection
SS-L
SS + integrated diaphragm leakage
detection
Gasket material
DDA 60-10 FCM-PVC/V/C-F-31U3U3FG
E EPDM
VFKM
TPTFE
Valve ball material
DDA 60-10 FCM-PVC/V/C-F-31U3U3FG
C Ceramics
SS Stainless steel 1.4401
Control cube
DDA 60-10 FCM-PVC/V/C-F-31U3U3FG
F
Front mounted (change to left or right is
possible)
Supply voltage
DDA 60-10 FCM-PVC/V/C-F-31U3U3FG
3 100-240 V 50/60 Hz single phase
Valve type
DDA 60-10 FCM-PVC/V/C-F-31U3U3FG
1 Standard
2 Spring-loaded
Connection, inlet / outlet
DDA 60-10 FCM-PVC/V/C-F-31U3U3FG
U3U3 2x Union nut G5/4
2x Hose connector 19/20 mm
2x Hose clamp
2x Pipe connector 25 mm
A7A7 2x Union nut G5/4
2x Inlay external thread 3/4 NPT
A1A1 2x Union nut G5/4 (SS)
2x Inlay internal thread Rp3/4 (SS)
A3A3 2x Union nut G5/4 (SS)
2x Inlay internal thread 3/4 NPT (SS)
Mains plug
DDA 60-10 FCM-PVC/V/C-F-31U3U3FG
F EU (Schuko)
B USA, Canada
GUK
I Australia, New Zealand, Taiwan
E Switzerland
J Japan
L Argentina
Design
DDA 60-10 FCM-PVC/V/C-F-31U3U3FG
G Grundfos red
A Grundfos green
B Grundfos black
X Neutral / black
Special variant
DDA 60-10 FCM-PVC/V/C-F-31U3U3FGC3
Standard
C3 Inspection certificate 3.1 (EN 10204)
