C-9105R
Conventional Reflective Beam Detector
Installation and Operation Manual The Intelligent Solution
3
certain way. Refer to details in Section VI Commission.
Normal monitoring state: Red LED flashes periodically.
Fire: Red LED constantly illuminates,. Fire alarm should be
cleared through powering up again.
Fault: Yellow LED constantly illuminates. The detector clears
the fault signal automatically if the condition causing the fault
disappears.
Optical pathway obscured totally: the detector first gives fault
signal and turns on Yellow LED. 20s later, it alarms fire,
illuminates Red LED and turns off Yellow LED. Note: In this
case, it does not mean there is a fire. After the obscuration
is removed, the detector clears fault signal automatically.
Fire signal has to be cleared by powering up the detector
again.
(8) Operating Environment:
Temperature: -10°C～+50°C
Relative Humidity≤95%, non condensing
(9) Monitoring Area: Maximum monitoring area: 14×100＝1400m
2
Maximum width: 14m
(10) Length of Optical Pathway: 8m～100m
(11) Protection Level:
Under common environment, ingress protection rating is IP20.
Under special environment, ingress protection rating is IP66
through glue-seal treatment.
(12) Dimension: length: 206mm width: 95mm thickness: 95mm
(13) Material and Color of Enclosure: ABS, gray
(14) Weight: 450g
(15) Mounting Hole Spacing:
