GST GST-FT40N - 3 Panel Instruction; Appearance and Structure; The Front Surface

GST-FT40N
Fire Telephone Panel The Intelligent Solution
Page 2
Notes: words using within this file
Fire Telephone Panel (Panel): Installed in fire control center, the device can
communicate with field terminals, such as GST-FT40N.
Handset: Field device, which can communicate with fire control center, such as
P-9911(F) and P-9911(M).
Main panel: The No.1 panel in the fire telephone panel network
Sub-panel: Panels other than No.1 in the fire telephone panel network
3 Panel Instruction
3.1 Appearance and Structure
GST-FT40N fire telephone panel is rack mount type, the appearance is shown in Fig.3-1
GST-FT40N FIRE TELEPHONE PANEL
Fig.3-1
3.2 The front surface
