GTO 2000XLS - Troubleshooting Guide; Diagnostic Indicators

GTO 2000XLS Instruction Manual © 02.07.12 25
Troubleshooting Guide
If your gate opener does not function properly, use this guide or use the online troubleshooter at
http://support.gtoinc.com before calling the GTO Service Department.
VISUAL AND AUDIBLE DIAGNOSTIC INDICATORS
1. VISUAL INDICATORS:
a. Power LED (Green):
  •ON:ACpowerorSolarpowerispresent.
  •OFF:Thereisnoinputpower.
b. Status LED (Yellow): (while unit is running this LED will be OFF)
  •Rapidblinkinginrandompattern:GTO’stransmitter318MHzsignalisdetected.
  •ContinuouslyON:Batteryisinfastchargemode.
  •1Blinkevery2seconds:Batteryisinoatchargemode(batteryisfullycharged)
  •OFF:SwitchisintheOFFpositionorthereisnoinputpowerforatleast60seconds.
2. AUDIBLE INDICATORS (ALARM/BUZZER):
a. Beeps upon power up:
  •Thisisnormalselftestwhentheunitisturnedon.
b. Continuous beep after power up:
  •Unithaslearnednewtransmittercode,releasingthetransmitterbuttonwillshutoff
the alarm.
c. Rapid beeping:
  •Unithasencounteredtwo(2)obstructionswithoutreachingeitherlimit.(Powercycletoresetthealarm)
  •Transmitterwillnotoperatethegate.
  •Alarmwillautomaticallyshutoffafter5minutes;gatewillremaindisableduntilcontrolboxisrestarted.
d. 1 beep every 20 seconds:
  •Lowbatteryisdetected.
e. 1 beep every 2 second:
  •Positionsensorisopencircuit.CallGTOServicedepartment.
f. 2 beeps every 2 second:
  •Positionsensorisshortcircuit.CallGTOServicedepartment.
g. 1 or more beeps when attempting to activate the opener:
  •Blownfuse.
  •Batteryisextremelylowordamaged.
  •Looseconnectionfrombatterytocircuitboard.
3 . IF THE GATE STOPS AND REVERSES DIRECTION
a. Check the gate for binding or hinge damage.
b. Adjust stall force if necessary.
c. Check the position of the mounting brackets and readjust or tighten if necessary.
