Functions
Lifting capacity,
SWL .............................. 250 kg (550 lbs), 500 kg (1100 lbs)
Operation .........................................Hand control / IR
Sound level .............................................52 dB (A)
GH3 Twin
Lifting speed
85 kg (187 lbs) load 60 mm/sec (2.4 inch/sec)
150 kg (330 lbs) load 60 mm/sec (2.4 inch/sec)
Max capacity load, SWL 55 mm/sec (2.2 inch/sec)
Max 5 kg (11 lbs) load 60/100 mm/sec
Max 11 lbs load 2.4/3.9 inch/sec
Weight and materials
SWL .............................. 250 kg (550 lbs), 500 kg (1100 lbs)
Own weight, SWL 250 kg (550 lbs), 500 kg (1100 lbs) .....19.2 kg (42.3 lbs)
Covers ........Impact-resistant UL 94 V-0 ame retardant recyclable plastic
Digital Scale Specications (Non medical). Optional for GH3 Twin
Capacity ................................................ 0 – SWL
Accuracy .....................................+/- 0.1 % at max load
Repeatability ........................ < 0.1 kg at 0-250 kg (0 – 550 lbs)
................................ < 0.2 kg at 0-500 kg (0 – 1100 lbs)
Minimum weight ....................................... 5 kg (11 lbs)
Display type ....................................LCD in Hand Control
Class III Scale Specications. Supplementary module for GH3 Twin
Capacity .................................................0 - SWL
Accuracy class .................................................III
Weighing range .....................Single-interval or multi-range (dual)
Maximum number of Verication Scale Intervals. . . . . . . . . . . . . . . . . . . . 2000
Maximum capacity (Max) .............................200 kg to 700 kg
Verication Scale Interval(e1) ............................... ≥ 0.1 kg
Minimum capacity (Min) ........................................20 e
Maximum tare effect ........................................≤ -Max
Operational temperature, scale ........................ +10°C - +40°C
