7.00 Operation
To lift/lower and adjustment of chassis leg in/out
• To lift the patient press UP arrow and to lower
the patient press DOWN arrow on the hand
control or the control box.
• On GL5.2 mobile lifter the leg spread width
adjustment of the chassis is operated via the
sideways arrows on the hand control. To switch
between modes on hand control, one button
needs to be released before activating the next.
• Use maximum width setting when lifting to/from
wide chairs, or as necessary when lifting to/
from bed, toilet and oor.
• When not in use, the hand control is designed
to be placed on the push handle.
• When maneuvering the lifter the chassis legs
must be in the closed narrow position.
• The lifter will go into standby after 2 min.
without use.
