Batteries
The batteries supplied with the lifter are not fully charged on delivery.
The battery pack must be charged before use. A full charge is recommended,
duration approximately 4 hours.
6.02 Checklist before use
• The lifter must be o󰀨 charge.
• Before rst use the service indicator must be reset, done by pressing up and
down button at the same time for 5 seconds.
• Check the lifter is lifting and lowering and the legs are opening and closing,
if you hear the audio warning (a beeping sound) DO NOT USE THE LIFTER
– it needs to be charged.
• Check that the green light located on the hand control is illuminated when the
lifter is activated.
• Check that the emergency stop and lowering is working (See section 5.02
safety features).
• Make sure the lifter is running freely.
• Check the slings for damage or fraying.
Once you have tted the sling (see section 8.01 - How to use the sling) you
are ready to lift.
With the user in a seated position
• If the user is in a wheelchair or commode chair the brakes must be applied.
• Open the lifter’s chassis leg width adjustment to allow access around the
chair.
Working with the Mobile lifter
Always maintain a good working posture when applying the sling or working
with the lifter. When moving a person use the push handle and walk forward
and backwards with the lifter keeping the load as close as possible to your
body. NEVER pull or twist at arm’s length, this can cause injury to the helper.
6.03 Charging and installing battery
Before use, the battery needs to be fully
charged. For details, see 6.04 Charging
procedure.
Remove battery packaging and mount the
battery on top of the control box. The battery
is mounted and secured correctly after hearing
a click.
