8.00 Use of Mobile lifter
Lifting hanger
The lifting hanger can be mounted on the mobile lifter without the use of any
tools.
1. Hold the lifting hanger in the right hand
and press the yellow button using the
index nger as shown. The slot on the
lifting hanger’s top cover must face up
(g. 1).
2. Insert the lifting hanger in the slot on the
side of the lifting hanger’s top cover (g. 2).
3. Check that the yellow button has returned
to its locked position by checking that it is
ush with the cover of the lifting hanger
and that the strap attachment can rotate
freely (g. 3).
Fig. 1
Fig. 3
Fig. 2
8.01 How to use the Sling
Use slings with 4-6 lifting straps designed for tting on Guldmann lifting han-
ger as shown in the sling manual.
The Lifter can be positioned under a bed. It can be moved through normal doors.
The lifter can be used in wet areas, but must not be exposed to splash water.
The lifter is protected against corrosion (See 11.00 Environmental conditions).
The lifter can be used for multiple users. When moving the lifter to another
user, perform normal hygienic disinfection.
