REMOTE CONTROL
85
:SYSTem:CONFigure:SDIP:WIDTh
Set
Query
Description
Sets or queries the width of the surge/dip site.
Syntax
:SYSTem:CONFigure:SDIP:WIDTh
{<NR2>|MINimum|MAXimum}
Query Syntax
:SYSTem:CONFigure:SDIP:WIDTh?
[MINimum|MAXimum]
Parameter
<NR2>
Width in milliseconds
MINimum
Minimum width
MAXimum
Maximum width
Return parameter
<NR2>
Returns the width in ms.
:SYSTem:CONFigure:TRIGger:INPut
:SOURce
Set
Query
Description
Configures the source for the trigger input.
Equivalent to the Input Pin>Action settings when
Shift + 2[Trigger] is pressed using the front panel
controls.
Syntax
Query Syntax
:SYSTem:CONFigure:TRIGger:INPut:SOURce
{<NR1>|NONE|OUTPut|SETTing|PRESet|SDIP}
:SYSTem:CONFigure:TRIGger:INPut:SOURce?
Parameter
0 | NONE
No source is assigned.
1 | OUTPut
Turning the output on will generate a
trigger.
2 | SETTing
Changing a setting will generate a trigger.
3 | PRESet
Loading a preset will generate a trigger.
4 | SDIP
Surge/ dip will generate a trigger.
Return parameter
+0
No source is assigned.
+1
Turning the output on will generate a
trigger.
+2
Changing a setting will generate a trigger.
+3
Loading a preset will generate a trigger.
Example
:SYST:CONF:TRIG:INP:SOUR?
>0
No trigger source is assigned.
