Description of Circuit Theory
1) +10V Voltage reference circuit?
Start up the circuits of R306 and D302 to ensure the output voltage of OPA U301, PIN 1 is in positive status when power is on.
this moment, the output voltage of PIN 1 will pass through R307
to maintain the voltage of both ends of ZENER DIODE ZD301(6.2V)
to 6.2V. As OPA has the character of false short circuit, so U301 PIN3=6.2V, refer to the following formula:
Therefore, the OPA’s output voltage can be changed by adjusting the VR301 as shown in the following formula:
Vref=10V→ VR301=1.14kΩ
2) Voltage Adjusting Circuit
The R311, and R313 are voltage feedback attenuating resistors while R312 is to control the output of Reference voltage. Please refer to
the following formula:
If Vref=10V R311=52.3kΩ R313=20kΩ
And the R316, R317, C313, C314, and C315 are compensated circuits for voltage frequency.
3) Current Adjusting Circuit:
The U302 is an Error Amplifier with the gain at:
10V
10k
10k4.99kVR301
6.2
R305
R305R304VR301
6.2Vref ≅
++
=
++
=
R313
R313R311
VrefVout
+
=
36.15V
20k
72.3k
10
20k
20k52.3k
VrefVout ==
+
=
Vpin13Vpin12
VR303R322R321
R321
10VAR341Io ==
++
×=××
28.01
3.57k
100k
R342
R326
A ===
