Output Test lead Selection:
The Selection of Output Test Lead and Feedback Test Lead:
For safety assurance, please select the adequate output test lead according to the following list:
Conductor UL
(CSA)
Model
Wire No.
AWG
Component
pc/mm
Cross Section Area
(mm)
2
Outer
Diameter
mm
Maximum
Conductive
Resistor
Ω/km
Permissible
Current
A(amp)
24 11/0.16 0.22 0.64 88.6 7.64
22 17/0.16 0.34 0.78 62.5 10.0
20 21/0.18 0.53 0.95 39.5 13.1
18 34/0.18 0.87 1.21 24.4 17.2
16 26/0.254 1.32 1.53 15.6 22.6
14 41/0.254 2.08 2.03 9.90 30.4
12 65/0.254 3.29 2.35 6.24 40.6
1015
TEW
)
10 65/0.32 5.23 3.00 3.90 55.3
1. The ambient temperature of “Permissible Current” is at 40℃, the withstanding temperature of conductor is at 105℃
to the condition of the distributed single wire.
2. The permissible current listed as above is suggested to be used under 70%.
3. If the feedback test leads are in need, the level above UL(CSA) AW
G24, 22, 20… can be accepted. Besides, when the load is a
capacitive load, please use the twine wire by twisting (+)output test lead with (S+) feedback test lead. Same way used on (-
output test lead and (S-) feedback test lead.
4. When the current value exceeds above suggestive list, can select more wires used in parallel according to above list.
