14
Resolution
PAL Recording Resolution : 600i, D1, HD1.
Frame Rate
Setting of Frame Rate: PAL:0-25 frames/sec.
Quality
Setting of recording quality: Values 1-5. The bigger valve, the better quality.
Prerecord setting
Prerecording time when motion alarm. Values: 0-10 seconds.
Audio
On/Off the sound effects.
Encoding
Encoding of channel. Values: VBR or CBR.
Record schedule setup
Always and Schedule Record.
Record Schedule
Setup Operation
Front Panel & Remote
Controller
USB Mouse
Enter Select Item [Enter] [Left Click]
Select Channel [Up/Down] [Moving mouse wheel]
Select Time&Date [Up/Down/Left/Right] [Click/Drag-draw]
Return to Upper Menu [MENU] [Right Click]
Copy
(1)Select source (2) Select target (3) Press COPY icon to copy.
8.3 Alarm Setup
