14
Installation
3.3 Connection
The DR 5000 has three USB interfaces as a standard feature,
located on the back of the instrument (Figure 1).
The USB Type A interfaces are used for communications with a
printer, USB memory stick or keyboard. A USB memory stick is
used to update instrument software.
The USB Type B interface is used for communications with a PC.
The optional Hach Data Trans software (see section 5.2.6.3 on
page 31) must be installed on the PC for this use.
A USB hub may be used to connect several accessories at a time.
Note: USB cables must not be longer than 3 meters (10 feet).
These USB interfaces enable data and graphics to be output to a
Printer and a PC and upgrade of instrument software (see
section 6.8.2 on page 106).
Figure 1 Interfaces
1 USB type A 4 Fuse
2 USB type B 5 Plug in power supply
3 On/Off switch
