Hach DRB 200 Instrument Manual

9
Section 1 Introduction
The DRB 200 is supplied as two models, with either one or two
heating blocks (
Figure 1). The heating blocks can heat solutions
in round vials of various sizes at 37–165 °C for a period of 0–480
minutes. The small, 16 mm diameter openings on the heating
block are suitable for Hach COD, Unicell, TOC, and Test N’
Tube tests. The larger, 20 mm diameter openings are intended for
sample preparation reaction vessels, using the Metals Prep Set.
The DRB 200 has 6 stored and 3 programmable temperature
programs.
Figure 1 Front View of the DRB 200 Digital Reactor Block (2 Block Version)
1.1 Front Display
The instrument is operated using three touch-sensitive keys
located below the display (
Figure 1). The function of the key
depends on the display. If no function is shown for a specific key,
that key is not currently active.
The actual temperatures of the heating blocks and the remaining
time are visible in the display while temperature programs are
active.
1. Protective Lid
2. 20 mm Metal Prep Vials
3. 16 mm Digestion Vials
4. Right Heating Block
5. Keys
6. Display
7. Left Heating Block
7
6
2
3
2
4
5
1

Hach DRB 200 Specifications

General

Temperature Stability	±0.2 °C
Block Material	Aluminum
Display	Digital
Power Supply	100-240 V AC, 50/60 Hz
Block Capacity	16 mm diameter tubes
Number of Holes	Varies depending on block type (e.g., 40, 15)
Hole Diameter	16 mm
Temperature Range	37 - 165 °C (98.6 - 329 °F)
