Table of Contents
1 Online user manual on page 3
2 Product overview on page 3
3 Specifications on page 4
4 General information on page 5
5 Installation on page 7
6 Startup on page 12
7 User interface and navigation on page 13
8 Operation on page 16
9 Meter settings on page 18
10 Probe settings on page 19
11 Data management on page 19
12 Maintenance on page 20
13 Troubleshooting on page 21
14 Replacement parts on page 21
Section 1 Online user manual
This Basic User Manual contains less information than the User Manual, which is available on the
manufacturer's website.
Section 2 Product overview
The HQ Series portable meters are used with digital Intellical
1
probes to measure one or more water
quality parameters. Refer to Figure 1. The meter automatically recognizes the type of probe that is
connected. The meter can connect to a PC or USB storage device to transfer data that is saved in
the meter. The optional Hach Communication Dongle (HCD) connects the meter to Claros
™
.
The HQ Series portable meters are available in eight models. Table 1 shows the types of probes that
can connect to each model.
Figure 1 Product overview
1 Micro-USB connector 4 Keypad
2 LED indicator 5 Intellical probe ports (three probe-port option
shown)
3 Display
1
IntelliCAL
®
is a registered trademark of Hach Company in the U.S.A.
English 3
