Section 13 Troubleshooting
13.1 Use the on-screen troubleshooting instructions
The user interface has troubleshooting instructions to help correct problems that can occur during
measurements, calibrations and verifications. When a problem occurs, the display shows the error
or warning icon with a short description of the problem. Push the right arrow to see the
recommended procedures to correct the problem.
Section 14 Replacement parts
W A R N I N G
Personal injury hazard. Use of non-approved parts may cause personal injury, damage
to the instrument or equipment malfunction. The replacement parts in this section are
approved by the manufacturer.
Note: Product and Article numbers may vary for some selling regions. Contact the appropriate distributor or refer to
the company website for contact information.
Replacement parts
Description Item no.
Battery, lithium ion, 18650, 3200 mAh, English language LEZ015.99.00001
Battery, lithium ion, 18650, 3100 mAh, Chinese language LEZ015.80.00001
Cable, USB 2.0 plug type A to micro plug type B, 0.91 m (3 ft) LEZ015.99.00002
Field case for standard probes LEZ015.99.A001A
Field case for rugged probes LEZ015.99.A002A
Hand lanyard and dust plugs LEZ015.99.A005A
Kickstand with hand strap LEZ015.99.A003A
Protective glove LEZ015.99.A004A
USB power adapter, 5 VDC, 2 A, 100–240 VAC, US LEZ015.99.00006
USB power adapter, 5 VDC, 2 A, 100–240 VAC, EU + UK LEZ015.99.00004
USB power adapter, 5 VDC, 2 A, 100–240 VAC, China LEZ015.99.00005
USB power adapter, 5 VDC, 2 A, 100–240 VAC, ROW LEZ015.99.00007
English 21
