sales representative immediately. Figure 1 is an example and shows
the parts supplied with LPV445.99.00110. Other instruments come with
different components.
Figure 1 Product components
1 DR300 5 Storage case
2 AAA alkaline batteries 6 Reagents
3 Sample cells, 25 mm (10 mL),
glass
7 Hach Communication Dongle
(optional, supplied separately)
4 Sample cells, 1 cm (10 mL), plastic
Section 3 Install the batteries
W A R N I N G
Explosion hazard. Incorrect battery installation can cause the
release of explosive gases. Be sure that the batteries are of the
same approved chemical type and are inserted in the correct
orientation. Do not mix new and used batteries.
Refer to Figure 2 to install the batteries. Then, push to set the
instrument to on.
English 7
