Display description
The display shows 3 types of screens:
•
Measure—the most recent parameter measurement is shown with the
temperature and stabilization time.
• Calibration—the calibration standard values and temperature are
shown during a calibration.
• Standby—the screen is empty except for the measurement timer at
the bottom.
Figure 4 pH1 screen display
1 Main measurement value (pH or
ORP)
4 Measurement time (hh:mm:ss)
2 Main measurement units 5 Temperature
3 Battery indicator
Figure 5 DO6 screen display
1 Main measurement value (DO) 4 Measurement time (hh:mm:ss)
2 Main measurement units 5 Temperature
3 Battery indicator
English 7
